Application

• Designed to enclose electrical and/or electronic equipment and protect against harsh, industrial environments for wallmount applications.
• Impressive styling features like hidden hinges, attractive latching systems make the Eclipse a suitable addition to any high-tech equipment installation.
• A wide range of sizes and practical accessories make this product line a complete package.
• For high temperature applications, a gasket retainer may be required, please refer to factory.

Standards

• UL 508 Type 3R, 4 and 12
• CSA Type 3R, 4 and 12
• Complies with
  • NEMA 3R, 4 and 12
  • IEC 60529, IP66

Construction

• Formed 14 gauge steel.
• Smooth, continuously welded seams ground smooth.
• Door stiffeners are provided for increased strength and rigidity also designed to permit additional mounting options.
• Formed lip on enclosure to exclude flowing liquids and contaminants.
• Doors may be easily removed for modifications and are interchangeable.
• Oil resistant gaskets are permanently secured.
• Collar studs provided for mounting inner panel.
• Includes hardware kit with panel mounting nuts and sealing washers for wall mounting holes.
• Bonding stud provided on door and grounding stud installed in enclosure.
• Doors are secured with a three point key lockable handle.
• Hinges are constructed from 304 stainless steel.
• Key lockable handle is zinc diecast with black epoxy finish.
• Hinge pins are stainless steel.

Finish

• Cover and enclosure are phosphatized and finished with a recoatable powder inside and out with choice of ANSI 61 smooth Gray (GY) or RAL7035 textured light gray (LG).
• RAL7032 textured beige (CG) versions with gland plates are available as non-stock items.

Accessories

• Air conditioners
• Blowers
• Breather kits
• DIN rails
• DIN rail mounting kit
• Door stop kit
• Drip Shield Kit
• Filter fans
• Gland plates
• Heaters
• Handles
• Inner panels
• Literature pocket
• Replacement hinge pins
• Thermostats
• Touch up paint
• UL/CSA approved hardware kit
• Window kits
