"Contempra 4" Extra-Wide Welded Frame Rack Cabinets
C4RR Series
Features
- Shipped fully assembled
- Allows standard 19" rack mounting of equipment
- 30" (762 mm) width provides wider internal cabling space around rack mounted equipment
- Welded 14 gauge steel frame with reinforced corners
- Removable sides, doors and top for easy access
- Open bottom for cable access
- Four (4) - 3.5" (89 mm) cable entry holes in top for cable access (includes covers)
- Four (4) - 19" mounting rails with square holes and rack U markings to EIA standards
- Clear swing, lockable doors
- An overall height of 83.5" (2,121 mm) allows for easy movement through most doorways
- The seismic loading of the C4 cabinet was determined in accordance with the Uniform Building Code 1997 (UBC 97) for Seismic Zone 4 when used with part number C4K-Z4 - floor bolt down kit (see general accessories section below)
Assembly Includes
- (1) - Welded Steel Cabinet Frame - C4F
- (1) - Flush Plexi Door - C4D
- (1) - Flush Perforated Door - C4D
- (2) - Solid side panels - C4SP
- (4) - 19" Panel Rails (Square Holes) - C4PR
- (1) - Top Panel (Vented/Fan cutouts) - C4T
- (4) - Hole plugs - 3.50" (89 mm) diameter hole
| 30" Wide (DATACOM/LAN) Part No. |
Color | Panel Height | Overall Dimensions (In.) | |||
| Inches | Units | Width | Depth | Height | ||
| C4RR307731DBK1 Buy › | Black | 77 | 44 | 30 | 31.5 | 82.81 |
| C4RR307736DBK1 Buy › | Black | 77 | 44 | 30 | 36 | 82.81 |
| C4RR307742DBK1 Buy › | Black | 77 | 44 | 30 | 42 | 82.81 |
| 30" Wide (SERVER) Part No. |
Color | Panel Height | Overall Dimensions (In.) | |||
| Inches | Units | Width | Depth | Height | ||
| C4RR307736SBK1 Buy › | Black | 77 | 44 | 30 | 36 | 82.81 |
| C4RR307742SBK1 Buy › | Black | 77 | 44 | 30 | 42 | 82.81 |
| C4 Rack Specific Accessories Part No. |
Description |
| C4RHINGE Buy › | Right Hand Door Hinge |
| C4PR77SZPL Buy › | 19" Panel Rails with rack U markings (pair) |
| C4AR77SZPL Buy › | 19" Accessory Rail |
| C4VCM77BK1 Buy › | Vertical Cable Manager |
| Tops & Bottoms Part No. |
Description |
| C2T2423F4BK1 Buy › | Fan Top with 4 - 4.7" fans (30 x 31.5") |
| C2T2431F4BK1 Buy › | Fan Top with 4 - 4.7" fans (30 x 36") |
| C2T2436F4BK1 Buy › | Fan Top with 4 - 4.7" fans (30 x 42") |
| C2T2423F10BK1 Buy › | Fan Top with 10" fan (30 x 31.5") |
| C2T2431F10BK1 Buy › | Fan Top with 10" fan (30 x 36") |
| C2T2436F10BK1 Buy › | Fan Top with 10" fan (30 x 42") |
| C4B3031SBK1 Buy › | Solid Bottom (30 x 31.5") |
| C4B3036SBK1 Buy › | Solid Bottom (30 x 36") |
| C4B3042SBK1 Buy › | Solid Bottom (30 x 42") |
| General Accessories Part No. |
Description |
| CGH01 Buy › | Frame Joining Kit |
| C4K-Z4 Buy › | Floor Bolt Down Kit |
| 1425BH Buy › | Caster - Non-locking (4) |
| 1421ABK25 1421ABK100 |
10-32 x 0.63" black pan head screw with nylon washer - (Qty. 25) 10-32 x 0.63" black pan head screw with nylon washer - (Qty. 100) |
| 1421CNA25 1421CNA100 |
10-32 cage nuts - (Qty. 25) 10-32 cage nuts - (Qty. 100) |
| RMASU1925BK1 Buy › | 19" panel mount shelf - 25" deep, unvented, adj 25" to 35" |
| RMASU1930BK1 Buy › | 19" panel mount shelf - 30" deep, unvented, adj 30" to 40" |
| RMASV1925BK1 Buy › | 19" panel mount shelf - 25" deep, vented, adj 25" to 35" |
| RMASV1930BK1 Buy › | 19" panel mount shelf - 30" deep, vented, adj 30" to 40" |
