Heater
Features
- Designed to provide enclosed electronic, pneumatic, hydraulic and mechanical equipment with protection from low temperatures, condensation and corrosion.
- The PTC (Positive Temperature Coefficient) heater unit maintains a stable temperature environment within enclosures, allowing critical components to perform with consistent reliability for longer periods.
- Heating power adjusts to ambient temperature
- Push connectors for quick and easy wiring
| Part No. | Watts¹ | Max. Current² | L (inches) | Ship Wt. lbs |
| SHG14000 Buy › | 15W | 1.5A | 2.6 | 1 |
| SHG14001 Buy › | 30W | 3.0A | 2.6 | 1 |
| SHG14003 Buy › | 45W | 3.5A | 2.6 | 1 |
| SHG14005 Buy › | 60W | 2.5A | 5.5 | 1 |
| SHG14006 Buy › | 75W | 4.0A | 5.5 | 1 |
| SHG14007 Buy › | 100W | 4.5A | 5.5 | 1 |
| SHG14008 Buy › | 150W | 8.0A | 8.7 | 2 |
| ¹ At 68°F (20°C) ambient temperature. ² Inrush current |
||||
| Operating Voltage: | AC/DC 110- - 250 V |
| Heating Element: | PTC resistor, self regulating |
| Heating Body: | Anodized extruded aluminum |
| Connection: | Push-type terminals for stranded and solid wire 3 x AWG 20 AWG 16 (0.5 - 1.5 mm2 |
| Mounting: | Easily installed by clip mounting on 35 mm DIN rails (included) |
| Protection Class: | I, test voltage 1600 V |
| Protection: | IP20 |
| Approval: | UL Recognized Component, cUL Recognized Component, CE |
